 Topic: Icom IC-25 expanded RF (keyboard mod)
Icom IC-25 expanded RF (keyboard mod) [message #785] Wed, 17 August 2011 23:36
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
1. Set offset to 0.0

2. Select VFO (A).

3. Press and hold [SIMP/DUP] and [NOR/REV].

4. Dial in desired frequency.

5. Release [SIMP/DUP] button.

6. Select the other VFO (B).

7. Repeat steps 3, 4, and 5

if VFO (B) can not be set, transfer VFO (A) VFO (B) using the [WRITE] button as described on page 7, item 6, of the owners manual.

Note: [SIMP/DUP] must be out when the VFO is changed.

If the tuning knob is turned again, the radio will revert back within the normal band range.
 Topic: IC-R7000 Audio Modifications
IC-R7000 Audio Modifications [message #385] Thu, 26 May 2011 23:08
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
The following modifications provide the following facilities.

- base band audio output, to utilizing digital transmissions such as AIS etc.
- a CTCSS filter insertion point, to eliminate annoying hum from the speaker Both these mods are best tackled at the same time.

1. Undo the screws holding the IF unit in position. Disconnect interconnecting cables.

2. As as indicated by the circuit diagram & board layout the baseband signal is taken from the discriminator output via a 10K resistor. Solder the 10K resistor to R97 on the solder side of the board and solder the other side to the inner braid of some thin audio coax cable. Connect the other end to the spare connector on the rear panel. Use some 3mm heat-shrink tube to cover the 10K resistor & hold in position with some hot glue. Connect the earth braid to a convenient earthing point with some insulated wire.

3. Remove C86 & connect some thin stereo coaxial cable (red = filter input & yellow=filter output) to each now empty pad. Connect the earth braid to a convenient earthing point with some insulated wire. The coaxial cable should be long enough to reach where the filter is installed. In my case I put this at the bottom where the IR receiver & Speech unit can be mounted.

4. Re-install the IF unit by screwing it in position & restoring the interconnecting cables.

5. An essential requirement is that both the input & output of the filter are capacitively coupled. For the filter unit, I used a recovered a CTCSS board from a Motorola SYNTRX FM radio. It contains the essential HP filter required to filter out the CTCSS tones, but in addition it contains a LP filter, which I will use to feed a CTCSS detector/display ( for info purposes). I used a hacksaw to cut off only the circuitry that I wanted. Alternatively a filter could be home brewed.

6. A switch could be provided to to enable straight through audio should this be required.

http://www.hamradio.cc//images/forum/mods/IC-R7000_baseband_CTCSS_modifications-1.jpg
Illustration 1: IF Unit modifications

http://www.hamradio.cc//images/forum/mods/IC-R7000_baseband_CTCSS_modifications-2.jpg
Illustration 2: IF unit modification locations

http://www.hamradio.cc//images/forum/mods/IC-R7000_baseband_CTCSS_modifications-3.jpg
Illustration 3: Typical CTCSS filterboard
 Topic: Icom IC-9100 Mod - Partial TX
Icom IC-9100 Mod - Partial TX [message #340] Tue, 05 April 2011 00:21
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
There are several ranges that can be selected by arranging diodes. First you can choose to only open up some areas and leave other frequencies (non amateur bands) locked.

40m amateur bands expansion (7.00MHz - 7.300MHz) : remove diode D1517
60m band expansion (5.255MHz - 5.405MHz) : remove diode D1515

index.php?t=getfile&id=42&private=0

Assemble radio.

Reset radio (full reset) by holding [F-INP ENT] and [M-CLR] and turn power ON.

[Updated on: Tue, 05 April 2011 00:26]

 Topic: Icom IC-9100 Mod - RX Expansion
Icom IC-9100 Mod - RX Expansion [message #339] Tue, 05 April 2011 00:13
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
RX-range: 30kHz - 60MHz, 180MHz - 174MHz, 420MHz - 480MHz, 1240MHz - 1320MHz

Locate diodes behind front panel.

Remove diodes D1504 and D1505 for full RX.

Assemble radio.

Reset radio (full reset) by holding [F-INP ENT] and [M-CLR] and turn power ON.

index.php?t=getfile&id=41&private=0

 Topic: AM transmitter enable for the Icom IC-745
AM transmitter enable for the Icom IC-745 [message #310] Sun, 23 January 2011 01:23
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
Intro:

After returning home from purchasing a used (but in good condition) ICOM IC-745, initial check out revealed the transmitter did not function in AM transmit mode. A look and the owners manual revealed: "AM Receive Only" What!!!??? This is supposed to be an ALL MODE RADIO! In reality the words used were..."ALL BAND HF RADIO"

After analyzing this perplex situation I came to the conclusion ICOM must have been doing their part in trying to save precious spectral bandwidth by not incorporating AM transmit in this particular model.
No one really utilizes AM mode these days (including myself) but this radio has every mode ever conceived and to leave AM transmit out really aggravated me!

Below is the Mod of Mods for IC-745 owners:

(All Modifications administered to the "MAIN UNIT" board located under the top cover of the radio.) (Except for R21 Removal on the logic board for the Power Mod.)
Parts List:

8 pin diodes. Factory Diodes are P/N 1SS53. 1N914's are fine.
3 10k resistors 1/4 watt.
1 NPN TO-92 pkg. switching TX, 2N3904 or equivalent is fine.
Source Voltage Terminology and Locations:

R8 = 8 Volt Receive Mode Source
AM8 = 8 Volt AM Mode Source
FM8 = 8 Volt FM Mode Source
CW8 = 8 Volt CW Mode Source
RY8 = 8 Volt RTTY Mode Source
USB8 = 8 Volt USB Mode Source
LSB8 = 8 Volt LSB Mode Source
                          ______________________
                         |                     |
        "J7"      Pin #1 | O O O O O O O O O O | Pin #10
     Main Board          |_____________________|
                           | | | | | | | | | |
                           --- --- | | --- ---
                            A   R  U L  C   F
                            M   Y  S S  W   M
                            8   8  B B  8   8
                                   8 8

                               -----------
        "J21"           Pin #1 | O O O O | Pin #4
       Main Board              -----------
                                 | | | |
                                 -------
                                   R8

THE MOD

1.

Pull up the anode end of Diode D44. (located by TX Q39) Build the additional circuit below. This will enable the B+ to the product detector and 9 Mhz BFO oscillator.
The 9Mhz osc will now be working for AM transmit as well as BFO Rec.


                      C
                        o to AM8  (Where the Anode of D44 was)
                         \\
                          \\| B       10K      1N914
                           |------\\/\\/\\/\\/-----|<-----o to R8
                          /|
      to R239 o----|<----/    2N3904 or Equivalent
                  D44    E

2.

Remove R66. (Located by TX Q13) Relocate and solder one end of R66 to the bottom of the board. (The end that goes to R23 and R30)

(The schematic shows a "BREAK" in the land. By removing the resistor from the PC board this simulates the break.)

Solder two 1N914's to the other end of R66. (Cathode ends of course)

Note: All pin assemblies will be connected on the underside of the Main Unit PC board.

This is part of the Mode selection process, and turns off the mike shunt in AM mode. (So audio can pass to the Balanced Modulator.)
      to R23 & R30   o-----\\/\\/\\/--:----|<----o   Anode to CW8
                                   |
                            R66    :----|<----o   Anode to RY8
                            10K     pair 1N914's (add)

3.

Solder one 1N914 diode (Cathode end) to the cathode connection of D15 (by TX Q19) under the board. Connect the anode to AM8.
This will enable the B+ to the Mic Amp stages and VOX ckts.
              to R31 (10K)
               ^
               |
               |
              ___
             break
              ___
               |           D15
               |------------|<----------------o Goes to 8 Volt LSB
      Source
               |------------|<----------------o Connect to AM8
      Source
               |
               |           1N914 (add)

              to R100 (100 Ohms)

4.

Remove R31 (Located by TX Q8) Relocate and solder one end of R31 to the bottom of the board. (The end that goes to R30 and the base of Q8)

(The schematic shows a "BREAK" in the land. By removing the resistor from the PC board this simulates the break.)

Solder Three 1N914's to the other end of R31. (Cathode ends) Tie the Anode ends to LSB8, USB8, FM8. Function: This portion of the mod will turn Q8 off in the AM mode to unbalance the balanced Modulator (IC1) for AM full carrier operation.
                       C
                        o                      3 1N914's (add)
                         \\
                (Q8)      \\| B         R31     |--|<-----o to  LSB8
              Bal/^Bal     |---------\\/\\/\\/\\/--|--|<-----o to  USB8
              switch      /|  |   |            |--|<-----o to  FM8
                for      /    |   |
                IC1     o     \\   \\
                      E       /   /
                          R29 \\   \\ R30
                              /   /
                              |   |     R's=10K's
                             ___  |
                              _   o

5.

Remove R24 (Located by TX Q7, "Mike Shunt Ckt") Solder a 1N914 Diode (Cathode end) into one of the pc holes that R24 came out of. (The one end that connects to R65 by Xtal X1.) Tie the anode to AM8.
This will enable the 9 Mhz CW xtal to generate the correct center frequency for AM.
          --
       o-||||--->|-o
          --  |
          X1  \\
              /
          R64 \\                         1N914 (add)
          10K /       R65
              |-----\\/\\/\\/\\--------------|<------o AM8
             ___      220     |
         C44 ___              ---|<---o to CW8
         47pf |
             ---                D13
              -

6.

AM Power Level Adjust (optional)Due to the duty cycle requirements of AM, output power of 40/50 Watts RMS should be the limit. Use the Front panel RF adj to reduce the output from 100 Watts or do the following:
1.

Connect a small 22 gauge (or so) wire from AM8 to the anode of Diode D26 by TX Q20. Add a series 10K resistor.
                AM8 o------\\/\\/\\/\\---------- o-->|-----o to Q20
                             10K             |  D26
               |________________________|    o
                        Add this             o S1
                                             |

2.

Set the 50/100 Watt power switch (S1) in the 100 Watt Position if you desire 100 watt operation of SSB,CW,RTTY.
3.

Adjust R116 (in AM xmit mode) for a power output of 40 Watts RMS.
4.

What were doing here is using the 50 Watt low power ckt as the AM power adjustment control.
Paralleling another connection to FM8 will allow FM to be reduced in similar fashion (as well as AM) instead of the factory 100% duty cycle.
                FM8 o---->|-------/\\/\\/\\/----o
                        1N914    |  10K      |
                AM8 o---->|-------           o-->|-----o to Q20
                        1N914                |  D26
                                             o
                                             o S1
                                             |

Note: When 10 Meters is selected port 28M (pin 47, IC3 on the logic unit) goes high, this turns on pin diode D27 on the main unit. This ultimately turns on the 50 watt (low Power) ckt allowing only low power operation from 28-30 Mhz?
I don't know why Icom did this? My guess is for 10 Meter FM overlooking the fact SSB/CW will be running reduced also. You may want to remove R21 (10K) on the logic board to remedy this situation. After R21 is removed you can limit the duty cycle on AM & FM as follows:
          FM8 o----\\/\\/\\/\\----->|----
                     10K   |   D27   |
                           |         |
          AM8 o----\\/\\/\\/\\----->|-------o to Q20
                     10K   |   D26
                           |
                           o
                           o  S1
                           |

Low power Adjustment R116 will now adjust output power for FM as well as AM.

Operation/conclusion:

The above AM/FM power mod is recommended. Higher power levels (Greater then 70/80 Watts RMS) result in severe distortion of the AM output signal.

Surprisingly the audio quality is quite good on AM xmit. (40/50 Watts) Several on the air discerning ears concluded the fidelity was quite acceptable. (Even from the Johnson Viking Guys on 3.880 (+-)).

For you skeptics wondering how an AM signal can sound acceptable through a 3Khz wide 455Khz SSB filter....................???

A quick turn to the schematic on the IF board depicts filter F-I1. (Ceramic filter CFW-455IT) This filter is a 6Khz wide ceramic filter used for AM receive mode. After the completion of the Mod this filter will be used for AM xmit also, by default! >>> It's in there!!

(Wasn't that a commercial once?)

Filter F-I2 (ceramic Filter CFT-455K14) or the optional FL-44A (SSB filter) is in operation for all other modes except FM. The optional FM board employs it's own filter arrangement.

That's it. Your all mode radio is now all mode!

73 Paul N2FAN

*05/2000

I have scanned the Main Board and Logic Board to depict the electrical changes made to the circuits. I tried to nicely re-label all the changes using VISIO technical, but I ran into some offset problems.

The hand written changes will have to do for now until I can get Visio to work right. If you have any questions about this Mod feel free to ask via e-mail only (I'm hard to get a hold of) e-mail = n2fan@glensummit.com

This is not an easy cut the wire mod, you will need to have some good electronic technician skills. PhD's forget it! ...............

This Mod works, I still have my IC-745 after 8 years!

73 and Good Luck!
 Topic: ICOM IC-756 Expand Transmit Frequency Mod
ICOM IC-756 Expand Transmit Frequency Mod [message #307] Sun, 16 January 2011 23:58
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
Notice: ICOM does not guarantee this to expand the frequency.

How to change full coverage transmit:
Remove the W805 jumper chip on MAIN board with a soldering iron.
Locate the jumper matrix located near the IC803.

What to do:
Remove bottom cover of ICOM IC-756. On the MAIN board you will see IF filters and a daughter board (DSP filter) on the right side. The W805 jumper and IC803 chip is lohoneyed under the DSP board. You have to remove the DSP board (carefully) and look for the part labeled IC803 and the line of jumpers (little green parts). When done, unsolder the W805 jumper. Install the DSP board and put the bottom cover back.
                     ---------------
         [W801]     |               |
         [W802]     |               |
         [W803]     |    IC 803     |
         [W804]     |               |
REMOVE==>[W805]     |     CHIP      |
         [W806]     |               |
         [W807]      ---------------
         [W808]

This info is from the ICOM SERVICE INFORMATION sheet.
http://www.hamradio.cc/images/forum/mods/ICOM-ic-756tx-mod.jpg

[Updated on: Mon, 17 January 2011 00:02]

 Topic: Icom IC-77 Mars Mod - tx expansion
Icom IC-77 Mars Mod - tx expansion [message #306] Wed, 12 January 2011 04:03
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
For Ham Mod remove the lower RIGHT diode (d14) from the pcb behind the lock button. it looks like this:

[d12] [d13]
[d11] [d14]

For TX expansion you have to leave (d11) intact and take the diode (d14) that you removed and install it at (d13).

http://www.hamradio.cc/images/forum/mods/icom_ic-77_Ham-TX-exp-1.jpg

If the diodes are all gone and no original diodes can be obtained normal 1N4007 diodes or similar can be used.

http://www.hamradio.cc/images/forum/mods/icom_ic-77_Ham-TX-exp-2.jpg

http://www.hamradio.cc/images/forum/mods/icom_ic-77_Ham-TX-exp-3.jpg

Author: V51JP

[Updated on: Wed, 12 January 2011 04:06]

 Topic: Icom IC-A20 Mod Extend Frequency
Icom IC-A20 Mod Extend Frequency [message #305] Tue, 11 January 2011 01:20
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
To extend frequency range (high end)from 135.975 to 136.975 MHz on the Icom IC-A20, proceed as follows:

1. Remove 4 screws holding back panel,
2. Remove 4 screws holding battery clip,
3. Remove battery clip and separate front and rear halves of radio
4. Remove 4 screws holding VOR unit mounted on the front panel so as to reveal Logic Unit.
5. Looking at the component side of the Logic Unit(opposite side to buttons and display), locate D711,
6. Directly above D711 You will see 3 empty pads in a triangle (SO-23 outline, this is where You need to fit a diode. The original diode used is 1SS187, but any SMD diode will do, or even a standard small wire ended diode. Solder anode to UPPER pad, and cathode to LOWER LEFT pad.
7. Reassemble the radio and reset CPU by holding Function and Clear buttons while powering up the radio.
8. Test the extended frequency range to see if mod was successful (mine was)118.000 to 136.975 MHz.

Den
 Topic: ICOM IC-V8000 Power Mod - Transistor Replacement
ICOM IC-V8000 Power Mod - Transistor Replacement [message #218] Sat, 26 December 2009 09:27
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
After the power transistor 2SC1971 blow up Adnan Al-ZADJALI replaced it with another 2SK3075. This transistor was more available and easier to get, and at the same time it also added a little more power, from 68 to 71 watt.


[Updated on: Sat, 26 December 2009 09:30]

 Topic: Icom IC2200H FM Discriminator Lohoneyion
Icom IC2200H FM Discriminator Lohoneyion [message #187] Wed, 19 November 2008 22:43
fungkh  is currently offline fungkh
Messages: 2
Registered: September 2008
Location: Keningau
Junior Member

Hello all, someone could help me the lohoneyion of Icom IC2200H FM discriminator/SQL location on board? Thank you

[Updated on: Tue, 30 December 2008 23:41]

 Topic: IC-7200 Band Voltage Modification
IC-7200 Band Voltage Modification [message #179] Fri, 29 August 2008 21:40
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
IC-7200 Band Voltage Modification
If you want to connect an external unit which can be controlled by the band voltatge from [ACC] connector, the modifihoneyion is necessary as in pdf attached.
The band voltage appears from pin 5 of [ACC] connector after modifihoneyion (1) is completed, or the regulated 8 V appears from pin 1 of [ACC] connector after modifihoneyion (2) is completed.

Performing this mod is the customer's responsibility. Icom does not guarantee this modifihoneyion's result.

[Updated on: Fri, 29 August 2008 21:46]

 Topic: IC-2200H MOD for extended RX/TX range
IC-2200H MOD for extended RX/TX range [message #94] Tue, 09 January 2007 23:31
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
RX receive circuitry can be modified to receive from 118 MHz to 174 MHz. This requires the removal of a surface mount diode D 11 from the Logic Board. It is the only non SMT-Diode of the Logic Board.

TX transmit circuitry can be modified to transmit from 136 MHz to 174 MHz. This requires the removal of a surface mount diode D 13 from the Logic Board. D 13 is near by D 11.

73, 55 de Wolf, DL5DKW

Thanks to hs9dih for this schematic.
Forum: Digital Modes
 Topic: PACKRATT PK-232 Mods - Eliminate Noise
PACKRATT PK-232 Mods - Eliminate Noise [message #3039] Sun, 01 June 2014 19:22
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
The following information was received from Wolf, ZS6AQC, concerning new Eproms for the PK-232 PAKRATT, plus a modification to eliminate noise from the op-amps. On recommendation of OM Piet, ZS6AQC I checked the noise in the power bus to the MC34074P op-amps and found (just like he said) that there is a lot of rubbish between the pins 4 and 11 of U23, 26, 28,30, 32 and 34. So, I placed some 1 microFarad caps across them and my receive noise is much less (measured on a mark=space scope cross display). In fact, I can now even copy some steady signals that don't even raise the S-meter needle. Hope you can improve yours also? This was received from OD5NG: he made this mod and results were outstanding.

Then Clark, W9CD made the modification and was pleased with the results. Consequently, I bought from Radio Shack 6 each 1 MF tantalum capacitors ("condensers" to Old Timers), and mounted them on the bottom of the board, with the shortest possible leads in the positions described above. The results are OUTSTANDING!!! RTTY signals I could not copy before are now perfect copy, even when you can barely see the traces on the scope. ARQ links, which could not be made before, now flow smoothly. The only thing I don't know if the mod will work if the latest version of the PK232 firmware upgrade is not installed, but I would think that it will. Give it a try and you will be pleasantly surprised.

P.S.: The part number for the referenced capacitors is:
Radio Shack # 272-1434, 1 MFD 35 Volts (Tantalum). Cost $ .59 each.
 Topic: Digital Mode Samples
Digital Mode Samples [message #1251] Sat, 11 February 2012 04:15
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
KB9UKD has a great archive of digital modes and their audio files (what they sound like).

http://www.kb9ukd.com/digital/
 Topic: Packet
Packet [message #378] Sun, 22 May 2011 12:08
W2EVU  is currently offline W2EVU
Messages: 1
Registered: May 2011
Location: Sodus Point, NY
Junior Member
I am looking for a packet program that will work with Windows 7 and a Yeasu FT-897D transceiver. I would prefer a soundcard program, but a TNC program would do.


W2EVU
 Topic: PSK31 Frequencies
PSK31 Frequencies [message #18] Fri, 04 March 2005 00:40
kc2nda  is currently offline kc2nda
Messages: 29
Registered: December 2004
Location: New Paltz
Junior Member
Here is the list of frequencies I have for PSK31 so far:

2 Meters = 145.550 and 145.140
10 Meters = 28.120
15 Meters = 21.070
20 Meters = 14.070.150
30 Meters = 10.142
40 Meters = 7.035
80 Meters = 3.580


If there are any more hot spots, please post them. Thanks.


KC2NDA

[Updated on: Mon, 07 March 2005 00:54]

Forum: General Chat
 Topic: Buy Samsung Galaxy S5 SV SM $550/Samsung Note3+Gear$450/Samsung GalaxyS4$360
Buy Samsung Galaxy S5 SV SM $550/Samsung Note3+Gear$450/Samsung GalaxyS4$360 [message #3038] Tue, 27 May 2014 05:25
pepmusley  is currently offline pepmusley
Messages: 3
Registered: May 2014
Location: United States
Junior Member
WE GLADLY WELCOME!! YOU TO MUSLEY STORE LIMITED®

MUSLEY STORE LIMITED® NOW OFFER A ANNUAL SALE!!!

We are dealers of all kinds of Mobile Phones Such as Apple Iphone, Blackberry, Nokia, Samsung, HTC, Sony Ericsson and many more. All our products are brand new, Original, comes with complete accessories and they also come with 1 year international warranty.

We also give 90 days return policy on every products that has been paid for and delivered to it owner, if within this days your equipment develop any fault or damages you can return it back to us: We make shipment through FedEx Express/UPS/DHL Services within 48hrs to your doorstep.

Our Offer!
Buy 2 Get 1 Free
Buy 3 Get 1 Free + Free Shipping
Buy 5 Get 2 Free + Free Shipping

Contact :: Mr Darren Fowler
Store :: Mobile & Gadgets Department

PLACE YOUR ORDER WITH US @ MUSLEY STORE LTD

For purchase enquiry you can contact us via any email below... SATISFACTION GUARANTEED
Contact Name : Darren Fowler
Email : musleyltd@musetr.com
Skype : musleyltd
BBM 24Hrs Chat : 25F0DE33

Apple Iphone:
Apple iPhone 5S 16GB ....$450USD
Apple iPhone 5S 32GB ....$500USD
Apple iPhone 5S 64GB ....$550USD

Apple iPhone 5C 16GB ....$380USD
Apple iPhone 5C 32GB ....$400USD

Apple iphone 5S 64GB 24K Gold : $1,200 USD
Apple iphone 5S 32GB 24K Gold : $1,000 USD
Apple iphone 5S 16GB 24K Gold : $900 USD

Apple Iphone 5 64GB .....$370 USD
Apple Iphone 5 32GB .....$350 USD
Apple Iphone 5 16GB .....$330 USD

Apple Ipad:
Apple iPad 5 Air Wi-Fi + 4G 128GB ....$530 USD
Apple iPad 5 Air Wi-Fi + 4G 64GB .... $500 USD
Apple iPad 5 Air Wi-Fi + 4G 32GB .... $430 USD
Apple iPad 5 Air Wi-Fi + 4G 16GB .... $400 USD
Apple iPad mini 2 Wi-Fi + 4G 64GB .... $430 USD
Apple iPad mini 2 Wi-Fi + 4G 32GB .... $400 USD
Apple iPad mini 2 Wi-Fi + 4G 16GB .... $380 USD
Apple iPad 4 Wi-Fi + 4G 64GB .... $390 USD
Apple iPad 4 Wi-Fi + 4G 32GB .... $370 USD
Apple iPad 4 Wi-Fi + 4G 16GB .... $350 USD
Apple iPad mini Wi-Fi + 4G 64GB.... $380 USD
Apple iPad mini Wi-Fi + 4G 32GB.... $360 USD
Apple iPad mini Wi-Fi + 4G 16GB.... $350 USD
Apple IPad 3 WiFi + 4G 64GB .... $340 USD
Apple IPad 3 WiFi + 4G 32GB .... $320 USD
Apple IPad 3 WiFi + 4G 16GB .... $300 USD

Sony PlayStation 4 - 500 GB .... $350 USD
Xbox One Console.........................$400 USD

BLACKBERRY PORSCHE DESIGN P9981 24K GOLD .... $800 USD
BLACKBERRY PORSCHE DESIGN P9981 BLACK/WHITE .... $500 USD

Blackberry:
BlackBerry Porsche Design P'9982 ..... $600USD
BlackBerry Z3 ..... $500USD
Blackberry Z30 .....$400USD
BlackBerry Q10 ...... $350USD
BlackBerry Q5 ..... $330USD
BlackBerry Z10 ...... $300USD
BlackBerry Porsche Design P'9981....$500USD
BlackBerry Porsche P9981 WITH SPECIAL PIN $600USD
Blackberry TK Victory......$380USD
BlackBerry Playbook WiMax.......$340.00USD
BlackBerry 4G Playbook LTE......$300.00USD
BlackBerry 4G Playbook HSPA+.....$310.00USD
BlackBerry 4G 64GB PlayBook Wi-Fi Table......$320USD

Samsung:
Samsung Galaxy S5 SV SM 32GB .... $550USD
Samsung Galaxy S5 .... $500 USD
Samsung Galaxy S5 + Galaxy Gear 2 :: $600 USD
Samsung Galaxy Note Pro 12.2 LTE SM-P905 .... $490 USD
Samsung Galaxy Note 3 Neo Duos SM-N7502 .... $480USD
Samsung Galaxy Note 3 Neo SM-N7505 .... $470USD
Samsung Galaxy Note 3 + Galaxy Gear .....$450 USD
Samsung Galaxy Note 10.1 (2014 Edition)....$430USD
Samsung Galaxy Note 3 N9005.....$400USD
Samsung Galaxy Grand 2 ..... $350USD
Samsung Galaxy Tab 3 8.0.........$400USD
Samsung I9506 Galaxy S4 ...... $360USD
Samsung I9505 Galaxy S4 .....$360USD
Samsung Galaxy S4 zoom .....$360USD
Samsung Galaxy Mega 6.3 I9200.....$400USD
Samsung Galaxy Note 8.0 N5100....$400USD
Samsung Galaxy Tab 3 10.1 P5220.....$400USD
Samsung Galaxy Note II N7100.......$300USD
Samsung I9190 Galaxy S4 mini.......$360USD
Samsung Galaxy Gear Smartwatch ..... $200 USD
Samsung I9300 Galaxy S III.....$300USD
Samsung Galaxy Note LTE 10.1 N8020.....$390USD
Samsung Galaxy Note 10.1 N8000....$400USD
Samsung I8190 Galaxy S III Mini....$280USD
Samsung Rex 80 S5222R ..... $320USD
Samsung I8530 Galaxy Beam......$270USD
Samsung Galaxy Tab 2 10.1.....$260USD
Samsung U380 Brightside.............$250USD
Samsung I9070 Galaxy S Advance.....$260USD
Samsung Galaxy Player 70 Plus......$250USD
Samsung I9105 Galaxy S II Plus....$230USD
Samsung Galaxy Y S5360.........$200USD
Samsung Galaxy Note N7000 .......$260USD
Samsung Galaxy Pocket S5300.......$220USD
Samsung Galaxy Note SGH-1717.....$240USD
Samsung I9100 Galaxy S II.....$190USD
Samsung Galaxy Tab 10.1.....$190USD

Nokia:
Nokia XL ..... $370 USD
Nokia X+ ..... $350 USD
Nokia X ..... $340 USD
Nokia Lumia Icon/929 .... $330USD
Nokia Lumia 1520.....$350 USD
Nokia Lumia 1020.....$340USD
Nokia Lumia 925......$330USD
Nokia Lumia 928......$300USD
Nokia Lumia 920......$290USD
Nokia Lumia 820......$280USD
Nokia Asha 311......$260USD
Nokia 808 PureView....$270USD
Nokia N9....$240USD
Nokia Lumia 900....$250USD
Nokia Lumia 800....$240USD
Nokia Lumia 710....$230USD

HTC:
HTC One ( M8 ) ..... $400 USD
HTC One (M7) ..... $350 USD
HTC 8XT ..... $370 USD
HTC One Max 803s .... $370 USD
HTC Butterfly S .... $360 USD
HTC Desire 600 Dual Dim.....$350 USD
HTC One....$340 USD
HTC One mini...$330 USD
HTC First...$320USD
HTC Trophy.....$300USD
HTC One VX.....$300USD
HTC One X+.....$290USD
HTC One X......$290USD
HTC One XL.....$270USD
HTC One S......$260USD
HTC One V......$250USD

Sony Ericsson:
Sony Xperia Z2 .... $400 USD
Sony Xperia Z1 ..... $390 USD
Sony Xperia Z Ultra .....$380 USD
Sony Xperia Z .....$360 USD
Sony Xperia M .....$350 USD
Sony Xperia L .....$340 USD
Sony Xperia V .....$320 USD

Motorola:
Motorola DROID RAZR MAXX......$300USD
Motorola MT917......$300USD
Motorola XT928......$300USD
Motorola RAZR XT912......$290USD
Motorola RAZR XT910......$280USD

Sony PlayStation 4 - 500 GB .... $350 USD
Xbox One Console.........................$400 USD

Other Mobiles:
LG G2 --- $380USD
Google Nexus 5 ----$350USD
Motorola Moto G ----$350USD
AT&T Z998 ---- $270USD

Samsung Galaxy S5 16GB Unlocked....$500 USD
Samsung Galaxy S5 32GB Unlocked....$550 USD

Available as:
Samsung SM G900F/SM G900H for Europe
Samsung SM G900I for Asia
Samsung SM G900K/G900L/G900S for Korea
Samsung SM G900M for Vodafone
Samsung SM G900A for AT&T
Samsung SM G900T for T Mobile
Samsung SM G900V for Verizon
Samsung SM G900R4 for US Cellular
Samsung SM G900P for Sprint

Others ::
Canon XH A1 Mini DV Digital Camcorder $700 USD
Canon EOS 5D Mark II .... $650 USD
HP ENVY 14 Beats edition series...... $999.99 USD
Bose® Lifestyle 235 Home Entertainment System ........... $1,599 USD
Bose® Lifestyle V25 Home Entertainment System ........... $1,610 USD
Apple MacBook Air - Core 2 Duo 2.13 GHz - 13.3 ------ 400.00 USD
Leica S-Adapter for Hasselblad H-System Lenses
Leica | 50mm f/0.95 Noctilux M Aspherical Manual Focus Lens
Leica S - Type 006 - Digital Medium Format Slr Camera Body
Miller 903471 XMT 304 CC/CV 208-230/460 W/Auto-Link.....$1,700 USD

PLACE YOUR ORDER WITH US @ MUSLEY STORE LTD

For purchase enquiry you can contact us via any email below... SATISFACTION GUARANTEED
Contact Name : Darren Fowler
Email : musleyltd@musetr.com
Skype : musleyltd
BBM 24Hrs Chat : 25F0DE33

MGT
 Topic: VHF Marine Radio Service Frequency Table
VHF Marine Radio Service Frequency Table [message #30] Thu, 10 November 2005 00:39
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
This table is the frequency chart for the VHF Marine Radio Service. There are specifically designated channels for specific usage, as indicated in the chart below. Frequencies are in megahertz. Note that the letter A indicates simplex use of the ship station transmit side of an international duplex channel, and that operations are different than international operations on that channel. Some VHF transceivers are equipped with an \"International - U.S.\" switch for that purpose. A channels are generally only used in the United States, and use is normally not recognized or allowed outside the U.S. The letter B indicates simplex use of the coast station transmit side of an international duplex channel. The U.S. does not currently use B channels for simplex communications in this band. Boaters should normally use channels listed as Non-Commercial. Channel 16 is used for calling other stations or for distress alerting. Channel 13 should be used to contact a ship when there is danger of collision. All ships of length 20m or greater are required to guard VHF channel 13, in addition to VHF channel 16, when operating within U.S. territorial waters. Users may be fined by the FCC for improper use of these channels. See the Federal Communications Commission\'s Marine VHF Radio Channels page for detailed information.

Marine VHF Designated Frequencies
Channel Number Ship Transmit
MHz Ship Receive
MHz Intended And Designated Use
01A 156.050 156.050 Port Operations and Commercial, VTS. Available only in New Orleans / Lower Mississippi area.
05A 156.250 156.250 Port Operations or VTS in the Houston, New Orleans and Seattle areas.
06 156.300 156.300 Intership Safety
07A 156.350 156.350 Commercial
08 156.400 156.400 Commercial (Intership only)
09 156.450 156.450 Boater Calling. Commercial and Non-Commercial.
10 156.500 156.500 Commercial
11 156.550 156.550 Commercial. VTS in selected areas.
12 156.600 156.600 Port Operations. VTS in selected areas.
13 156.650 156.650 Intership Navigation Safety (Bridge-to-bridge). Ships >20m length maintain a listening watch on this channel in US waters.
14 156.700 156.700 Port Operations. VTS in selected areas.
15 -- 156.750 Environmental (Receive only). Used by Clbass C EPIRBs.
16 156.800 156.800 International Distress, Safety and Calling. Ships required to carry radio, USCG, and most coast stations maintain a listening watch on this channel.
17 156.850 156.850 State Control
18A 156.900 156.900 Commercial
19A 156.950 156.950 Commercial
20 157.000 161.600 Port Operations (duplex)
20A 157.000 157.000 Port Operations
21A 157.050 157.050 U.S. Coast Guard only
22A 157.100 157.100 Coast Guard Liaison and Maritime Safety Information Broadcasts. Broadcasts announced on channel 16.
23A 157.150 157.150 U.S. Coast Guard only
24 157.200 161.800 Public Correspondence (Marine Operator)
25 157.250 161.850 Public Correspondence (Marine Operator)
26 157.300 161.900 Public Correspondence (Marine Operator)
27 157.350 161.950 Public Correspondence (Marine Operator)
28 157.400 162.000 Public Correspondence (Marine Operator)
63A 156.175 156.175 Port Operations and Commercial, VTS. Available only in New Orleans / Lower Mississippi area.
65A 156.275 156.275 Port Operations
66A 156.325 156.325 Port Operations
67 156.375 156.375 Commercial. Used for Bridge-to-bridge communications in lower Mississippi River. Intership only.
68 156.425 156.425 Non-Commercial
69 156.475 156.475 Non-Commercial
70 156.525 156.525 Digital Selective Calling (voice communications not allowed)
71 156.575 156.575 Non-Commercial
72 156.625 156.625 Non-Commercial (Intership only)
73 156.675 156.675 Port Operations
74 156.725 156.725 Port Operations
77 156.875 156.875 Port Operations (Intership only)
78A 156.925 156.925 Non-Commercial
79A 156.975 156.975 Commercial. Non-Commercial in Great Lakes only
80A 157.025 157.025 Commercial. Non-Commercial in Great Lakes only
81A 157.075 157.075 U.S. Government only - Environmental protection operations.
82A 157.125 157.125 U.S. Government only
83A 157.175 157.175 U.S. Coast Guard only
84 157.225 161.825 Public Correspondence (Marine Operator)
85 157.275 161.875 Public Correspondence (Marine Operator)
86 157.325 161.925 Public Correspondence (Marine Operator)
87 157.375 161.975 Public Correspondence (Marine Operator)
88 157.425 162.025 Public Correspondence only near Canadian border.
88A 157.425 157.425 Commercial, Intership only.
NOAA Weather WX1 162.550
NOAA Weather WX2 162.400
NOAA Weather WX3 162.475
NOAA Weather WX4 162.425
NOAA Weather WX5 162.450
NOAA Weather WX6 162.500
NOAA Weather WX7 162.525
 Topic: 900 Mhz Cordless Phone Frequency Information
900 Mhz Cordless Phone Frequency Information [message #29] Thu, 10 November 2005 00:37
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
These tables are frequency information for the 900 Mhz cordless phone frequencies. This frequency range is still active and phones are still in manufacture for it. Information will change most likely. These listings are only for information as it is illegal to monitor, record or disclose the contents of a cellular or cordless telephone conservation! In order to test the phone operation via scanner, it is necessary to program the BASE frequency to enable both sides of the conversation.


900 MHZ CORDLESS TELEPHONE FREQUENCIES - - 902 - 928 MHZ NFM
Panasonic KX-T9000 (60 Channels)
base 902.100 - 903.870 Base frequencies (30Khz spacing)
handset 926.100 - 927.870 Handset frequencies
CH BASE HANDSET CH BASE HANDSET CH BASE HANDSET
-- ------- ------- -- ------- ------- -- ------- -------
01 902.100 926.100 11 902.400 926.400 21 902.700 926.700
02 902.130 926.130 12 902.430 926.430 22 902.730 926.730
03 902.160 926.160 13 902.460 926.460 23 902.760 926.760
04 902.190 926.190 14 902.490 926.490 24 902.790 926.790
05 902.220 926.220 15 902.520 926.520 25 902.820 926.820
06 902.250 926.250 16 902.550 926.550 26 902.850 926.850
07 902.280 926.280 17 902.580 926.580 27 902.880 926.880
08 902.310 926.310 18 902.610 926.610 28 902.910 926.910
09 902.340 926.340 19 902.640 926.640 29 902.940 926.940
10 902.370 926.370 20 902.670 926.670 30 902.970 926.970

CH BASE HANDSET CH BASE HANDSET CH BASE HANDSET
-- ------- ------- -- ------- ------- -- ------- -------
31 903.000 927.000 41 903.300 927.300 51 903.600 927.600
32 903.030 927.030 42 903.330 927.330 52 903.630 927.630
33 903.060 927.060 43 903.360 927.360 53 903.660 927.660
34 903.090 927.090 44 903.390 927.390 54 903.690 927.690
35 903.120 927.120 45 903.420 927.420 55 903.720 927.720
36 903.150 927.150 46 903.450 927.450 56 903.750 927.750
37 903.180 927.180 47 903.480 927.480 57 903.780 927.780
38 903.210 927.210 48 903.510 927.510 58 903.810 927.810
39 903.240 927.240 49 903.540 927.540 59 903.840 927.840
40 903.270 927.270 50 903.570 927.570 60 903.870 927.870


For the single frequency model Panasonic phones, the color of the unit
often determines which of the above channels is used by the phone. The
following chart lists these allohoneyions.

Color of Phone CH BASE HANDSET
-------------- -- -------- --------
Blue 01 902.1000 926.1000
Hot Pink 02 902.1300 926.1300
Banana 03 902.1600 926.1600
Cerise 04 902.1900 926.1900
White 05 902.2200 926.2200
Off White 06 902.2500 926.2500
Gray 07 902.2800 926.2800
Fuschia 08 902.3100 926.3100
Shocking Pink 09 902.3400 926.3400
Chartreuse 10 902.3700 926.3700
Neon Purple 11 902.4000 926.4000
Black 59 903.8700 927.8700


V-TECH TROPEZ DX900 (20 CHANNELS)
905.6000 - 907.5000 TRANSPONDER (BASE) FREQUENCIES (100 KHZ SPACING)
925.5000 - 927.4000 HANDSET FREQUENCIES
CH BASE HANDSET CH BASE HANDSET CH BASE HANDSET
-- ---- ------- -- ---- ------- -- ------- -------
01 905.6000 925.5000 08 906.3000 926.2000 15 907.0000 926.9000
02 905.7000 925.6000 09 906.4000 926.3000 16 907.1000 927.0000
03 905.8000 925.7000 10 906.5000 926.4000 17 907.2000 927.1000
04 905.9000 925.8000 11 906.6000 926.5000 18 907.3000 927.2000
05 906.0000 925.9000 12 906.7000 926.6000 19 907.4000 927.3000
06 906.1000 926.0000 13 906.8000 926.7000 20 907.5000 927.4000
07 906.2000 926.1000 14 906.9000 926.8000


GE 2-9925 (30 Channels)
Base 902.1250 - 903.9850 Base frequencies (60Khz spacing)
Handset 926.1250 - 927.9850 Handset frequencies
CH BASE HANDSET CH BASE HANDSET CH BASE HANDSET
-- -------- -------- -- -------- -------- -- ------ --------
01 902.1250 926.1250 11 902.7250 926.7250 21 903.3250 927.3250
02 902.1850 926.1850 12 902.7850 926.7850 22 903.3850 927.3850
03 902.2450 926.2450 13 902.8450 926.8450 23 903.4450 927.4450
04 902.3050 926.3050 14 902.9050 926.9050 24 903.5050 927.5050
05 902.3650 926.3650 15 902.9650 926.9650 25 903.5650 927.5650
06 902.4250 926.4250 16 903.0250 927.0250 26 903.6250 927.6250
07 902.4850 926.4850 17 903.0850 927.0850 27 903.6850 927.6850
08 902.5450 926.5450 18 903.1450 927.1450 28 903.7450 927.7450
09 902.6050 926.6050 19 903.2050 927.2050 29 903.8050 927.8050
10 902.6650 926.6650 20 903.2650 927.2650 30 903.8650 927.8650
31 903.9250 927.9250 32 903.9850 927.9850



OTHER 900 MHZ CORDLESS PHONES
AT&T #9120 - - - - - 902.0 - 905.0 & 925.0 - 928.0 MHZ
OTRON CORP. #CP-1000 902.1 - 903.9 & 926.1 - 927.9 MHZ
SAMSUNG #SP-R912- - - 903.0 & 927.0 MHZ

[Updated on: Thu, 10 November 2005 00:38]

 Topic: 49 Mhz Cordless Phone Frequency Table
49 Mhz Cordless Phone Frequency Table [message #28] Thu, 10 November 2005 00:36
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
This table is the frequency chart for the 49 Mhz cordless phone frequencies. These listings are only for information as it is illegal to monitor, record or disclose the contents of a cellular or cordless telephone conservation! In 1991 and again in late 1995, the FCC added additional frequencies to the 49 Mhz section for these phones, and changed the frequency shift from the base frequency and handset. Hence, for this division of cordless phones, there are three sections, pre 1991, pre and post 1995. In order to test the phone operation via scanner, it is necessary to program the BASE frequency to enable both sides of the conversation. As you can see from the chart, some of the frequencies overlap and can, in certain instances, cause problems for other units. Also be aware that baby monitor channels also fell into the 49 Mhz telephone range and OFTEN cause problems.

PRE-1991 CORDLESS FREQUENCIES

Channel ## Base TX Handset TX
========== ======= =======
Channel 01A 49.9300 01.6950
Channel 06A 49.8300 01.7050
Channel 13A 49.8600 01.7650
Channel 19A 49.8750 01.7950
Channel 25A 49.8900 01.8250
Channel 27A 49.8450 01.7350

PRE-1995 CORDLESS FREQUENCIES

Channel Base Handset Baby Monitor
Old-New Frequencies Channel
=====================================
01 16 46.610 49.670
02 17 46.630 49.845 B
03 18 46.670 49.860 C
04 19 46.710 49.770
05 20 46.730 49.875 D
06 21 46.770 49.830 A
07 22 46.830 49.890 E
08 23 46.870 49.930
09 24 46.930 49.990
10 25 46.970 49.970

POST-1995 CORDLESS FREQUENCIES

Channel Base Handset
===========================
1 43.7200 48.7600
2 43.7400 48.8400
3 43.8200 48.8600
4 43.8400 48.9200
5 43.9200 49.0200
6 43.9600 49.0800
7 44.1200 49.1000
8 44.1600 49.1600
9 44.1800 49.2000
10 44.2000 49.2400
11 44.3200 49.2800
12 44.3600 49.3600
13 44.4000 49.4000
14 44.4600 49.4600
15 44.4800 49.5000
16 46.6100 49.6700
17 46.6300 49.8450
18 46.6700 49.8600
19 46.7100 49.7700
20 46.7300 49.8570
21 46.7700 49.8300
22 46.8300 49.8900
23 46.8700 49.9300
24 46.9300 49.9900
25 46.9700 49.9700
 Topic: Citizens Band Radio Frequency Table
Citizens Band Radio Frequency Table [message #27] Thu, 10 November 2005 00:33
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
This table is the frequency chart for the legal Citizens Band Radio Service. There are 40 channels, designated 1 through 40. The service is AM but also allows for SSB operation on radios that are capable. CB, as it is called, is a two-way voice communihoneyion service for use in your personal and business activities. Expect a communihoneyion range of one to five miles. License documents are neither needed or issued. CB Rule 3 provides your authority to operate a CB unit in places where the FCC regulates radiocommunihoneyions, as long as you use only an unmodified FCC certifihoneyed CB unit ( CB Rule 9 ). An FCC certifihoneyed unit has an identifying label placed on it by the manufacturer. Per the FCC, there is no age or citizenship requirement. You may operate your CB unit within the territorial limits of the fifty United States, the District of Columbia, and the Caribbean and Pacific Insular areas (\\\\\\\"U.S.\\\\\\\"). You may also operate your CB on or over any other area of the world, except within the territorial limits of areas where radio-communihoneyions are regulated by another agency of the U.S. or within the territorial limits of any foreign government. You may also be permitted to use your CB unit in Canada subject to the rules of Industry Canada; other countries may also allow CB frequency use but it is your responsibility to verify that prior to use.

There are no height restrictions for antennas mounted on vehicles or for hand-held units ( CB Rule 8 ). For structures, the highest point of your antenna must not be more than 20 feet above the highest point of the building or tree on which it is mounted, or 60 feet above the ground. There are lower height limits if your antenna structure is lohoneyed within two miles of an airport. You may use any of the 40 CB channels on a \\\\\\\"take-turns\\\\\\\" basis. These channels must be shared by all CB users. There are no channels authorized in the CB Radio Service above 27.405 MHz or below 26.965 MHz. No CB channel is bassigned to any specific individual or organization (CB Rule 7). Be cooperative. Keep your communihoneyions short. Never talk with another station for more than 5 minutes continuously. Then wait at least one minute before starting another communihoneyion (CB Rule 16). Use Channel 9 only for emergency communihoneyions or for traveler bassistance. For complete information, see the Commission\\\\\\\'s Rules for the Citizens Band (CB) Radio Service, 47 C.F.R. 95.401-95.428.


CHANNEL FREQUENCY CHANNEL FREQUENCY
1 26.965 MHz 21 27.215 MHz
2 26.975 MHz 22 27.225 MHz
3 26.985 MHz 23 27.255 MHz
4 27.005 MHz 24 27.235 MHz
5 27.015 MHz 25 27.245 MHz
6 27.025 MHz 26 27.265 MHz
7 27.035 MHz 27 27.275 MHz
8 27.055 MHz 28 27.285 MHz
9 27.065 MHz 29 27.295 MHz
10 27.075 MHz 30 27.305 MHz
11 27.085 MHz 31 27.315 MHz
12 27.105 MHz 32 27.325 MHz
13 27.115 MHz 33 27.335 MHz
14 27.125 MHz 34 27.345 MHz
15 27.135 MHz 35 27.355 MHz
16 27.155 MHz 36 27.365 MHz
17 27.165 MHz 37 27.375 MHz
18 27.175 MHz 38 27.385 MHz
19 27.185 MHz 39 27.395 MHz
20 27.205 MHz 40 27.405 MHz

[Updated on: Thu, 10 November 2005 00:35]

Forum: Arduino
 Topic: Arduino RS-232 to RS-485 Converter
Arduino RS-232 to RS-485 Converter [message #3033] Mon, 28 April 2014 22:51
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
If you have one of these RS-232 to RS-485 converters (probably bought from E-BAY):
 Arduino rs-485 to rs-232 Converter

You will probably get a description like this:

* It is able to convert RS-232 signal to RS-485 balanced differential signal and extend the communihoneyion distance to 1.2km.
* It uses a particular pump to gain power from RS-232 signal (RTS, DTR, TXD) without initializing the RS-232 series interface.
* This interface converter does this without requiring any AC or DC power.

You will have problems with this converter from the arduino unless you read the spec sheet. Unfortunately the sellers will probably not give you the schematic or tell you how the circuit works.

I used this converter along with an arduino using the TX and RX TTL output to a MAX232 circuit, then this plugged directly into the RS-232 to RS-485 converter which in turn was connected to the power meter.

The response from the arduino was perfect. Not problems. But the power meter was not receiving the correct data.

The problem that the sellers don't tell you very clearly is what is needed to power the converter.

The trick here is to read this sentence a few times to understand it: "It uses a particular pump to gain power from RS-232 signal (RTS, DTR, TXD) without initializing the RS-232 series interface." So in order to get this RS-232 to RS-485 converter to work, you will need to hook the RS-232 serial port's DTR and RTS pins to the 5V Pin on the arduino (or another source if you have it), pin 5 of the serial port to Ground on Arduino, and the TX and RX from the Arduino to the corresponding pins 2 and 3 on the RS-232 port.

Pin 4 (DTR) - Jumper these two pins and hook to 5V from arduino
Pin 7 (RTS)

Once this is done, the RS-485 device will have enough power to send the correct data through.

*You could get around all of this by just purchasing a RS-485 plug in module for the arduino. It will save you a lot of time since these modules will convert the data for you without having to go to a TTL to RS-232 conversion, then to RS-485.
 Arduino rs-485 Converter Module

[Updated on: Tue, 13 May 2014 02:16]

Forum: Yaesu Mods
 Topic: FT-301D Display Replacement Kit
FT-301D Display Replacement Kit [message #3026] Sat, 01 March 2014 03:58
HB9GAA  is currently offline HB9GAA
Messages: 1
Registered: February 2014
Location: Switzerland
Junior Member
Hi, I developed a kit to replace the display board for the FT- 301D. No SMD were used and the kit can be assembled by a radio amateur in about an hour . The new display has, in addition to the frequency display, various advanced features. For example, the supply voltage of the FT- 301D can be measured or the band limits according IARU can be signaled. For disabled HAMs the displayed frequency and voltage is output in Morse code. With an IR remote control parameters can be changed. The software can be updated via the USB interface. A user manual is available on http://shop.elcon.ch/pd-1503415091.htm?defaultVariants=searc h0_EQ_Bausatz_AND_{EOL}&categoryId=1 . The selling price of the kit, depending on demand, is about $90 plus S&H. If you are interested, please write me to hb9gaa@arrl.net 73 de HB9GAA, Roland
 Topic: Yaesu FTM-400 DR Extended Band Mod 136-174 / 400-480MHz
Yaesu FTM-400 DR Extended Band Mod 136-174 / 400-480MHz [message #3025] Tue, 21 January 2014 01:13
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
New frequencies after the modification:
136-174 mhz RX/TX
400-480 mhz RX/TX

1. Open the upper shell (speaker)

2. Lithium battery located on the left side

3. Identify positive symbol on lithium battery

4. Remove resistance as shown in photos

5. Perform a CPU reset (page 61)

http://www.hamradio.cc/images/forum/mods/5130_FTM-400-MOD2_thumb.JPG

http://www.hamradio.cc/images/forum/mods/5130_ftm-400-mod1_thumb.JPG

*NOTE: Mod will not work on US version

[Updated on: Tue, 21 January 2014 01:17]

 Topic: Yaesu VX-8R Mod Out of band
Yaesu VX-8R Mod Out of band [message #2995] Sat, 06 July 2013 00:13
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
The software mod did not work at all. Then I initially cut the track leading from the resistor, without actually removing the resistor. This opened up the 1.2m band (220 Mhz, which was not available prior to cutting the track)but did not expand the other bands.

Later, I actually removed the resistor. This opened up the other bands, the 2 meter band now has a working bottom edge at 140 Mhz, everything (including ARS) works.

I suspect that the software mod would now also work, and I could change the country code as described in an earlier post, but I haven't bothered as there isn't anything in the 130 - 140 Mhz range I am currently interested in. If anyone has a similar experience and also tries changing the country code via the software mod I would be interested in hearing about the experience.

by Donna Murray
 Topic: Yaesu FT-230R Problems
Yaesu FT-230R Problems [message #2991] Thu, 20 June 2013 00:09
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
Yaesu FT-230R Problems
NO RF OUTPUT : The PA module is a common failure on this unit.

NO RF OUTPUT WHEN HOT : PA.

NO RF OUTPUT IN THE LOW POWER POSITION : Check the PA.

RF OUTPUT INTERMITTENTLY FALLS OFF : I have seen two or three cases where the PA has intermittently gone into oscillation. In both cases this was due to internal faults within the PA module. It should be noted that this oscillation can be sufficient to blank out a nearby TV, and this fault should be suspected if there is a complaint of TVI. It should also be noted that the PA continues to oscillate and draw current when returning to receive, and EVEN IF THE FRONT PANEL POWER SWITCH IS TURNED OFF.

NO AUDIO OUTPUT : Suspect Q07 - the audio o/p IC.

MUFFLED AUDIO ON RX : Note there is an internal tone control (VR1001) on the main PCB. A lot of people don't know it's there.

OFF FREQUENCY TX AND RX : If this is only slight then align the PLL. If the error is significant then the local osc xtal should be checked.

BADLY BROKEN UP ON TX+RX : Check X03 (5.76MHz) in the PLL.

ERRATIC TUNING : Tuning step switch.

144-148MHz OPERATION : On the micro board there are spaces for four small tinned copper wire links next to each other. In normal UK versions, two links, J1 and J4 are made. Cut J1.

S-METER READING FALLS OFF AS UNIT WARMS UP : See Yaesu mod sheet.
Forum: Programming Radios
 Topic: ForSale CHEAP PRICE RADIO Kc6wir@yahoo.com
ForSale CHEAP PRICE RADIO Kc6wir@yahoo.com [message #3023] Mon, 04 November 2013 07:12
raymtcn73  is currently offline raymtcn73
Messages: 2
Registered: November 2013
Junior Member
Flex-5000 100 Watt SDR Transceiver ...........$1550 /1175 Euro ACOM 1000 ....................................$1600 /1215 Euro AmeritronAL-1500 .............................$2100 /1594 Euro QRO HF-2500DX 160-10M HF Amp .................$1600 /1215 Euro ICOM IC-7700 .................................$2200 /1670 Euro ICOM IC 9100 .................................$1600 /1215 Euro Icom IC-7000 .................................$750 /569 Euro Icom IC 775DSP ...............................$1100 /800 Euro Icom PW-1 ....................................$1700 /1290 Euro ICOM IC-756-Pro III ..........................$1200 /911 Euro KENWOOD TS-2000 ..............................$900 /650 Euro Kenwood TL-922A HF amp .......................$750 /569 Euro Alpha 9500 ...................................$3000 /2278 Euro Ten Tec Orion II .............................$1300 /987 Euro Ameritron A-l 1200 ...........................$800 /607 Euro Elecraft K2 ..................................$500 /379 Euro Elecraft K3/100 ..............................$1850 /1404 Euro Yaesu FTDX 9000MP ............................$5500 /4176 Euro Yaesu FTDX 5000MP ............................$3500 /2657 Euro Yaesu FTDX 3000MP ............................$1600 /1215 Euro YAESU FL-7000 SOLID STATE HF LINEAR AMPLIFIER.$1000 /725 Euro Yeasu FT-857D w/ LDG Tuner....................$620 /450 Euro Yaesu FT920 ..................................$750 /569 Euro I can ship worldwide. All radios are in a perfect working condition Kc6wir@yahoo.com +1 8323232144. kc6wir Raymond.

  • Attachment: Forums.jpg
    (Size: 46.82KB, Downloaded 195 time(s))

  • Attachment: Forums.jpg
    (Size: 46.82KB, Downloaded 120 time(s))

 Topic: MINT Elecraft K3/100
MINT Elecraft K3/100 [message #2987] Mon, 20 May 2013 02:06
raycoustier  is currently offline raycoustier
Messages: 3
Registered: May 2013
Junior Member
For Sale: Loaded Elecraft K3 and P3 panadapter with many options including the second receiver and antenna tuner. It was a kit but expertly assembled and it works and looks great. Below is the complete list of options: K3/100 - 100w Transceiver ......KBPF3 - gen coverage bandpass filter KDVR3 - digital voice recorder......KFL3A-500 - 500hz cw filter KFL3A-6K - 6khz AM filter..........KFL3B-FM - 13 khz FM filter KRX3- second receiver.......KTCXO3-1 - TCXO 0.5PPM KXV3A - K3 rx ant,IF out, Xvtr interface.....MH2 - Hand Mic P3- Panadapter Asking : $1850 shipped (worldwide) Contact : kc6wir@yahoo.com Icom IC-756 Pro III in as new condition from a non smoking environment. I purchased the radio new. The radio is pristine, no scratches,dings or marks and it works as it should. NO ISSUES ! Comes with PS-125 power supply microphone, power cord, manual and factory box and packing materials S/N 3203519. Price $1300.00 Mr. Ray Contact : kc6wir@yahoo.com (408) 419-9615 73 kc6wir
 Topic: Motorola mcs2000
Motorola mcs2000 [message #2819] Sun, 21 April 2013 03:54
motorolaxtl  is currently offline motorolaxtl
Messages: 1
Registered: April 2013
Location: Australia
Junior Member
Hi everybody I new to this site I recently bought a Motorola mcs2000 and I took it to a Motorola dealer in Australia and they told me that they used ver 2.00.00 software to read the radio Iam wondering if anybody has that software. Thank you in advance.
 Topic: About Radio
About Radio [message #1321] Thu, 12 April 2012 10:03
rubinaask  is currently offline rubinaask
Messages: 1
Registered: April 2012
Location: united states
Junior Member
Radio is the transmission of signals through free space by electromagnetic waves with frequencies significantly below visible light, in the radio frequency range, from about 3 kHz to 300 GHz.

[Updated on: Thu, 12 April 2012 11:01]


car vision
 Topic: Kenwood Software Programming Reference
Kenwood Software Programming Reference [message #155] Sat, 12 January 2008 17:12
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
SOFTWARE PROGRAMS THESE RADIOS

SOFTWARERADIOS
KPG-5DTK-930 TK-931
KPG-6D TK-705 TK-805
KPG-7DTK-630 TK-730 TK-830
KPG-11DTK-230 TK-330
KPG-15DKDS-10
KPG-16DTK-430 TK-431
KPG-21D TKB-720 TKR-720 TKR-820
KPG-23D TK-250 TK-350
KPG-25DM2 TK-840 TK-940 TK-941
KPG-26D TK-353
KPG-27D TK-260 TK-270 TK-360 TK-370
KPG-29D TK-760 TK-762 TK-860 TK-862
KPG-31D TK-255
KPG-35D TK-480 TK-481
KPG-38D TK-290 TK-390
KPG-41D TK-715
KPG-44D TK-690 TK-790 TK-890
KPG-47D TKR-830
KPG-48DTK-2100(K)(K2) TK-3100(K)(K2) TK-3101(K2)
KPG-49D TK-280 TK-380 TK-780 TK-880
KPG-56D"G" SERIES PORTABLES & MOBILES (260GK, 360GK, 270GK, 370GK, 760(H)GK, 860(H)GK, TK-762(H)GK, TK862(H)GK
KPG-79D TK-7150 TK-8150
KPG-81D TK-2160 TK-3160

RADIO PROGRAMMING CABLES PROGRAMMING CABLE PROGRAMS THESE RADIOS

CABLERADIOS
KPG-4 TK-705 TK-760 TK-762 TK-860 TK-862 TK-840 TK-930 TK-630 TK-730 TK-830
KPG-14 KDS-10 KCT-24S KVT-10 VH-C1
KPG-22 TK-250 TK-350 TK-260 TK-360 TK-353 TK-270 TK-370 TK-2100 TK-3100 TK-2160 TK-430 TK-431 TK-255 TK-715 TK-3160
KPG-36TK-280 TK-380 TK-290 TK-2140 TK-480 TK-481 TK-390 TK-3140
KPG-43 TK-690 TK-790 TK-890
KPG-46 or KPG-4 TK-780 TK-880 TK-980 TK-981 TKR-830 TK-7150 TK-8150
KPT-50 TKB-720 TKR-720 TKR-820

[Updated on: Wed, 23 May 2012 01:17]

 Topic: Motorola RSS Reference List
Motorola RSS Reference List [message #133] Mon, 21 May 2007 01:35
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
There is no guarantee of accuracy of this list...

Part # Media Operating
System
Product(s) Manual(s) RSS Ver License? Release Date RIB
Needed?
RIB-to-radio cable
HVN9054D 3.5 3.1, 95, 98 1225 6880904Z93 R03.2 RPX4719G 08/23/00 Yes 3080070N01
RVN4106B 3.5   "-10" PRODUCT CONFIG TOOL 6804005C75 R04.00.00   08/25/93
HVN9001D 3.5 3.1, 95, 98 1225LS 6880906Z25 R2.0 RPX4719G 12/15/00 Yes HLN9359A
RVN4057C 3.5 DOS 32x8 Codeplug 6881125E50 R01.01.01 RPX4719G 08/09/91 No 3080385B23 &
5880385B30
MDVN4964E 3.5   9100 System Upgrade N/A R02.01.00   01/03/95
RVN4126E 3.5   9100-386 & 9100-386T Devices 6804018C30 R01.60.00   01/31/97
MDVN4963C 3.5   9100-386 System Upgrade N/A R02.00.00   01/03/95
MDVN4965C 3.5   9100-WS/T Configuration N/A N/A   01/03/95
RVN4085C 3.5   Advanced Securenent CIU 6880310B58 R02.00.00 RPX4719G 01/11/94 No 0180358A25
RVN4185A CD 95, 98, ME, NT, 2000 Astro 25 Mobile   R01.00.00 RPX4719G 11/15/01 No NKN6545A
RVN4186A CD 95, 98, ME, NT, 2000 Astro 25 Mobile/Portable   R01.00.00 RPX4719G 11/15/01   RKN4105A /
RVN4106A
RVN4181A CD 95, 98, ME, NT, 2000 Astro 25 Portable   R01.00.00 RPX4719G 11/15/01   RKN4105A /
RVN4106A
RVN4053M 3.5   ASTRO Digital Interface 6802924C15 R7.01.11 RPX4719G 04/12/00 No 3080385B23
RVN4183B CD 95, 98, ME, NT, 2000 Astro Mobile   R01.01.00 RPX4719G 10/22/01 Yes RKN4047A
RVN4100U 3.5 DOS Astro Mobile/Portable N/A R09.01.00 NLA - SUBS TO RVN4184
RVN4184B CD 95, 98, ME, NT, 2000 Astro Mobile/Portable Combination   R01.01.00 RPX4719G 10/22/01 Yes RKN4046A (Port)
RKN4047A (Mob)
RVN4182B CD 95, 98, ME, NT, 2000 Astro Portable   R01.01.00 RPX4719G 10/22/01 Yes RKN4046A
RVN4154G 3.5   ASTROTAC 3000 Comparator 6881098E15 R03.07.00 RPX4719G 10/20/99   3080385B23
RVN5003D 3.5   ASTROTAC Comparators 6881087E80 R50.21.00 RPX4719G 06/19/96 No 3080399E31 Adapt.
5880385B34
RVN4131C 3.5   BLINKERS.EXE INSTR. SHEET VER.1.02 6880309G87 04/19/96
RVN4083A 3.5   BSC II 6880310B51 VR01.00 6880309G87 07/24/90 No FKN5836A
MDLN1058A 3.5 DOS C DEVELOPMENT APPL 6802705X01 R03.00.00   08/26/92
NTN1024C 3.5 DOS C DEVL'MT.RD-LAP APPL 6802705X01 R01.00.00   08/26/92
RVN4171B 3.5   C200   R01.01.00 RPX4719G 12/04/00
HVN9025H CD 95,95, 98, ME, NT, 2000 CDM PRO Series 6881088C46 R06.01.00 RLN4809A 11/14/00   AARKN4083
AARKN4081 Ribless
RVN4029K 3.5   CENTRACOM SERIES II 6881121E49 R09.05.02 RPX4719G 11/15/96 No VARIOUS
SEE MANUAL
RVN4112E 3.5   COMMANDPLUS 6880309E42   RPX4719G   No
RVN4149C 3.5   COMTEGRA 6881096E75 R04.00.00 RPX4719G 02/11/99 Yes 3082056X02
RVN4079G 3.5 DOS DESKTRAC CONVENTIONAL 6880310B53 MAXTRAC
R5.30.00
RPX4719G 05/09/95 Yes 3080070N01
RVN4093F 3.5 DOS DESKTRAC TRUNKED 6802982G55
6880310B61
R03.04.00 RPX4719G 12/13/1995 Yes 3080070N01
RVN4091C 3.5   DGT 9000 DESKSET 6880310B59 R01.00.11 RPX4719G 06/04/96 Yes 0180358A22
RVN4135A 3.5 DOS R100 (HVN9177) M100/M200,M110,M400 6880900Z22   RPX4719G 12/13/1995 Yes 0180358A52
HVN9025H CD 95,95, 98, ME, NT, 2000 EX500/600 6881088C46 R06.01.00 RLN4809A 11/14/00 Yes JMKN4123
RVN4107B 3.5 DOS FORMSGEN 9100-11 6881063C60 R03.06.00   12/13/1995
RVN4146C 3.5   FORTE Wireless CommPad 6802945C40 R02.02.09 RPX4719G 05/08/98
RVN4114A 3.5   GLOBAL POSITIONING SYS. 6880310B77 R01.00.00 RPX4719G 12/14/1995 No RKN4021A
HVN8177F 3.5   GM / GR300 / GR500 / GR400 / M10 / 12 / 130 6880902Z36
6880902Z64
6880903Z28
6880903Z67
R05.00.00 RPX4719G 12/13/1995 Yes 3080070N01
RVN4159A 3.5   GP 60 SERIES 6881086C08 R04.00.00 RPX4719G 12/27/96 Yes PMLN4074A
RVN4152C 3.5 DOS GP350 AVS 6880904Z32 R1.20 RPX4719G 01/23/98
RVN4152C 3.5 DOS GP350 AVS 6880904Z32 R08.02.00 RPX4719G 12/30/1997
RVN4150H 3.5 DOS GTX 6802948C70 R04.00.01 RPX4719G 10/13/00 Yes HKN9857(Portable)
3080070N01(Mobile)
RVN4047A 3.5 DOS HT 10 6881061C95 R01.00.06 RPX4719G 12/14/1995 Yes RTK4208B
RVN4021C 3.5 DOS HT 50 6881056C20 R02.00.00 RPX4719G 12/13/1995 Yes RTK4208B
RVN4005H 3.5 DOS HT600 (not HT600E) 6881045C55 R03.01.01 RPX4719G 04/03/01 Yes RTK4205C
RVN4031C 3.5 DOS HT800 6881058C65 R04.05.00 RPX4719G 12/13/1995 Yes RTK4205C
HVN9025K CD 95, 98, ME, NT, 2000 HT CDM/MTX/ER SERIES   CPS R06.02.03
PASSPORT R03.00.04
RLN4809A 7/17/2002 Yes AARKN4083
AARKN4081 Ribless
AARKN4075 Ribless non-USA
RKN4074
RVN4098H 3.5 DOS HT1000 / JT1000 / VISAR CONV'L 6881073C55 R03.03.00 RPX4719G 05/01/98 Yes RKN4035B(HT1000)
3080371E46(JT, VISAR CONV'L)
RVN4151B 3.5 DOS HT1000 AVS 6881084C35 R1.0 RPX4719G 08/30/97
HVN9025H CD 95,95, 98, ME, NT, 2000 HT750/HT1250 6881088C46 R06.01.00 RLN4809A 11/14/00 Yes RKN4074A
HVN9085B 3.5   i20R   R01.02.00 6880309G87 12/26/00 No HLN9359
PROG. STAND
HVN9084B 3.5   i750 6880904Z45 R01.00.08 6880309G87 11/12/1996 Yes HLN-9102A
RVN4174N CD 95, 98, ME, NT, 2000 iDEN SUPER AGENT   R01.13.00 RPX4719G 4/19/02
RVN4130D 3.5   INFOTAC MESSNG'R EDITOR 6804018C75
6804018C60
  R01.02.04 02/15/96
HVN6053D CD 95,95, 98, ME, NT, 2000 KARISMA (CT SERIES) N.A R02.01.03 RLN4995A 11/08/00 Yes AAPMKN4004
RVN4156N 3.5 DOS LCS/LTS 2000 6802946C20 R02.00.10 RPX4719G 8/24/2001 Yes HKN9857(Portable)
3080070N01(Mobile)
RVN4087A 3.5   LORAN C LOC. RECV'R. 6880103W13 R01.00.00 6880309G87 12/14/1995 No RKN4021A
RVN4135A 3.5 DOS M100/M200 (HVN9173) 6880900Z20   RPX4719G 09/22/94 Yes 3080070N01
RVN4135A 3.5 DOS M110 (HVN9646)     RPX4719G 09/22/94 Yes 3080070N01
RVN4135A 3.5 DOS M400 (HVN9774) 6880901Z68   RPX4719G 09/22/94 Yes 3080070N01
RVN4135A 3.5 DOS M100/M200, M110, M400, R100 includes HVN9173,9177,9646,9774 6880900Z20   RPX4719G 12/13/1995 Yes 3080070N01
RVN4023G 3.5 DOS MARATRAC 6880102W24 R05.00.00 RPX4719G 07/02/98 Yes 3080070N01
RVN4019K 3.5 DOS MAXTRAC CONVENTIONAL 6880900Z03 R07.02.00 RPX4719G 01/05/98 Yes 3080070N01
RVN4139C 3.5 DOS MAXTRAC LS 6881078C79 R03.00.00 RPX4719G 01/23/98 Yes 3080070N01
RVN4043S 3.5 DOS MAXTRAC TRK'D. 6880102W46 R05.07.03 RPX4719G 4/6/2000 Yes 3080070N01
RVN4178A CD   MC SERIES, MC2000/2500   R01.00.00 NONE 5/15/2001   DDN6124A (DB25)
DDN6367A (DB9)
VVN4190B 3.5   MCP GENERIC 6802903A48 R01.00.10 RPX4719G 02/06/96
RVN4027B 3.5   MCR 100 6881125E60 R01.10.00 6880309G87 12/14/1995
RVN4177G CD 95,95, 98, ME, NT, 2000 COMBINATION MCS/MTS   R01.05.14 RPX4719G 08/24/01
RVN4177K
combination of RVN4175 AND RVN4176 containing RVN4175, RVN4113, RVN4176, RVN4097, important notice sheet, letter
2-CD
2-3.5
95, 98, ME, NT, 2000, DOS MCS / MTS 6881081C15
6881074C50
R01.08.00 RPX4719G 06/18/02
RVN4175K contains: RVN4113 (DOS) important notice sheet, letter 1-CD 1-3.5 95, 98, ME, NT, 2000, DOS MCS 2000 6881081C15 R01.08.00 RPX4719G 6/18/2002   Rib to MIC connector RKN4062B
RVN4113K 3.5 DOS MCS2000 6881081C15 R05.05.00 NLA - SUBS TO RVN4175 Yes RKN4062(for PROG/CLONING)
RKN4063(for FLASH/TEST PROG)
RVN4011B 3.5 DOS MCX 1000 6802902A30 R02.02.00 RPX4719G 12/13/95 Yes 3000056M01
RVN4063A 3.5 DOS MCX 1000 MARINE 682990A02 R01.03.00 RPX4719G 12/14/1995 Yes 3000056M01
RVN4117C 3.5   MDC/RDLAP DEVICES 6804110L45 R03.04.00   12/29/1995
RVN4312A 3.5   MICOM 2 6802942C80 V2.0 RPX4719G 05/16/97 No FLN2423
RVN4105A 3.5   MOBILE PROG. TOOL 6804006C40 R03.00.00   12/14/1995
RVN4119C 3.5   MOBITEX DEVICES 6804016C65 R01.04.04   12/15/1995
RVN4037A 3.5 DOS MOSTAR CONVENTIONAL 6880900Z57 - NLA -   Yes 3080367B90
RVN4059C 3.5 DOS MOSTAR/TRAXAR TRK'D. 6881125E51 R01.01.01 RPX4719G 12/13/1995 No 3080367B90 / DUPLEX ADAPTER 0180359A29
RVN4128A 3.5   MPT1327-1200 SERIES 6802058U46
6802058U99
R02.02.00 RPX4719G 12/14/1995 Yes SEE MANUAL
RVN4025A 3.5   MSF 5000/PURC/ANALOG 6881121E08 V01.00.00 RPX4719G 12/13/1995 Yes 0180355A30
RVN4077G 3.5   MSF5000/10000 FIELD PROG DIGITAL 6881125E68 R05.21.00 RPX4719G 12/13/1995 Yes 0180355A30
RVN4017K 3.5 DOS MT 1000 6881050C20 R03.02.00 RPX4719G 5/18/2001 Yes RTK4205C
RVN4148M 3.5   MTR 2000 6881096E15 R03.02.06 RPX4719G 02/20/01 Yes 3082056X02
RVN4140C 3.5   MTRI 2000 6880309F68 R01.02.00 RPX4719G 02/17/99 No
RVN4176G CD 95,95, 98, ME, NT, 2000 MTS WINDOWS   R01.05.14 RPX4719G 08/24/01
RVN4176K contains RVN4097 (DOS) important notice sheet, letter 1-CD 1-3.5 95, 98, ME, NT, 2000, DOS MTS2000, MT2000*, MTX8000, MTX9000 *programmed by DOS which isincluded in the RVN4176 6881074C50 R01.08.00 RPX4719G 6/18/2002
RVN4097S 3.5 DOS MTSX/MT/MTS/MTX 6881074C50 R06.05.00 NLA - SUBS TO RVN4176 Yes RKN4035B
RVN4131C 3.5   MTVA CODE PLUG FIX INSTR SHEET   6880309G87 04/19/96
RVN4131C 3.5   MTVA CODE PLUG FIX INSTR SHEET VER.1.02 6880309G87 4/9/1996
RVN4142A 3.5   MTVA DOCTOR 6880309F67 R05.10.00 RPX4719G 12/14/1996 Yes 3080070N01
RVN4131C 3.5   MTVA3.EXE INSTR. SHEET VER.3.00 6880309G87 04/19/96
RVN4013K 3.5 DOS MTX 800 & 800S 6881054C10 R05.00.00 RPX4719G 01/05/98 Yes RTK4205C
RVN4065H 3.5 DOS MTX 810 6881065C25 R03.00.00 RPX4719G 01/05/98 Yes RTK4205C
RVN4033J 3.5 DOS MTX 900 6881068C85 R04.00.00 RPX4719G 01/05/98 Yes RTK4205C
RVN4055H 3.5 DOS MTX 900S 6881065C55 R04.00.00 RPX4719G 01/05/98 Yes RTK4205C
RVN4097 replaced by RVN4176 1-CD DOS MTX8000/9000 MTS2000,MT2000*, MTX8000, programmed by DOS which is included in the RVN4176
RVN4081F 3.5 DOS MTX820/820S/888/888S 6881068C55 R03.00.00 RPX4719G 01/05/98 Yes RTK4205C
HVN9067C CD 95, 98 MTX850/8250 MTX950,9250   R01.03.03 RLN4809A 12/21/2001
RVN4138B 3.5 DOS MTX-LS 6881078C83 R02.00.00 RPX4719G 06/13/96 Yes RKN4035D
RVN4035B 3.5 DOS MX 1000 6802002F01 R02.03.00 6880309G87 12/13/1995 Yes RTK4203C
RVN4073B 3.5 DOS MX 800 6881064C90 R01.01.00 RPX4719G 12/13/1995 Yes RKN4006B
RVN4134B 3.5 DOS P100 (HVN9175) P200 LB (HVN9794) P50+ (HVN9395) P210 (HVN9763) P500 (HVN9941) PR3000 (HVN9586) 6880901Z52   RPX4719G 7/27/2001 Yes RTK4205
HVN9852J 3.5 DOS P110   R08.00.03 RPX4719G 4/30/96 Yes HKN9755A/REX1143
HVN9262E 3.5 DOS P200 UHF/VHF 6881059C40 R03.01.00 RPX4719G 07/26/01 Yes RTK4205
RVN4129A 3.5   PDT220 6804020C10
6804018C10
R01.00.00   12/13/95
YVN4051C 3.5   PORTABLE REPEATER 6881075C70 R1.02.00 RPX4719G 5/21/1996   Portable repeater P1820 / P1821AX
RVN4061C 3.5 DOS PP 1000/500 6881125E52 R01.01.01 6880309G87 12/13/1995 No 3080385B23 &
5880385B30
RVN4134A 3.5 DOS PR3000 (HVN-9586) 6880901Z27   RPX4719G 09/22/94
RVN5002AE 3.5   QUANTAR/QUANTRO RECV. 6881092E25,
6881083E35,
6881096E10
R12.02.00 RPX4719G 6/13/2002 No 3O80369E31
RVN4135A 3.5 DOS R100 (HVN9177) 6880900Z22   RPX4719G 09/22/94 Yes 0180358A52
RVN4135A 3.5 DOS RADIUS MOBILES KIT FOR M100/M200, M110, M400, R100 6880900Z20
6880901Z68
6880900Z22
  RPX4719G 09/22/94 Yes
RVN4134A 3.5 DOS RADIUS PORTABLES KIT FOR P100, P500, P210, P200 LB, P50+, PR3000 6880901Z91
6880901Z55
6880901Z52
6880900Z56
6880901Z27
  RPX4719G 09/22/94 Yes HKN9755A
MDVN4747B 3.5   R-LINK DEVELOPMENT 6804026C35 R01.01.00   08/05/94
RVN4146C 3.5   RPM500/660 6802945C40 R02.02.09 RPX4719G 4/30/1998
RVN4002K 3.5 DOS SABER 6881062C95 R07.01.00 RPX4719G 12/13/95 Yes RTK4203C
RVN4131C 3.5   SETTLET.EXE INSTR. SHEET VER.5.10 6880309G87 4/9/1996
HVN9007E 3.5   SM50 & SM120 6880903Z78 R05.00.00 RPX4719G 9/1/98 Yes
RVN4039B 3.5 DOS SMART STATUS 6802976G45 R01.03.00 RPX4719G 12/13/95 Yes FKN5825A
HVN9054D 3.5 3.1, 95, 98 SOFTWARE P1225 6880904Z93 R03.2 RPX4719G 8/23/2000 Yes 3080070N01
HVN9001D 3.5 3.1, 95, 98 SOFTWARE 1225LS 6880906Z25 R2.0 RPX4719G 12/15/2000 Yes HLN9359A
HVN9012D 3.5   SP50 6880903Z25 R04.00.00 RPX4719G 9/2/1998
RVN4001N 3.5 DOS SPECTRA 6880101W48 R06.00.05 RPX4719G 12/13/1995 Yes 3080369B73(standard)
0180300B10(high pwr)
RVN4099B 3.5 DOS SPECTRA RAILROAD 6802903A55 R04.05.01 RPX4719G 12/13/95 Yes 3080369B73
RVN4110A 3.5   STATION ACCESS MODULE 6880309E35 R01.01.00 RPX4719G 12/13/1995 No 3080369E31
RVN4049E 3.5 DOS STX 6881065C30 R03.01.00 6880309G87 12/13/1995 Yes 0180357A54
RVN4089A 3.5 DOS STX TRANSIT 6881069C55 R01.01.00 6880309G87 12/14/1995 Yes 0180357A54
RVN4007E 3.5 DOS SYNTOR X 9000 (control head) 6880309B25
6880309B26
CH-R07.11 RPX4719G 08/16/94 Yes 0180353A75
RVN4007E 3.5 DOS SYNTOR X 9000 (radio) 6880309B24
6880309B25
6880309B26
RD-R08.01 RPX4719G 12/13/1995 Yes 0180353A75
RVN4102A 3.5 DOS SYNTOR X 9000 DUAL 6807992D52 D07.03.SP01 RPX4719G 12/14/1995 Yes 0180353A75
RVN4069A 3.5 DOS SYNTOR X TRK'D. 6880310B42 R01.00.00 6880309G87 12/13/1995 Yes 0180353A75
RVN4009F 3.5 DOS SYSTEM 9000E 6880101W98 R04.10.04 RPX4719G 12/13/1995 Yes 0180353A75
RVN4051F 3.5 DOS SYSTEMS SABER 6881060C25 R04.00.00 6880309G87 12/13/1995 Yes RTK4203B
RVN4075D 3.5   T5600/T5620 SERIES 6802981G35 R04.00.02 RPX4719G 12/13/1995 No 3080385B23
HVN9060D CD   TC3000, TS3000, TR3000   R01.02.01.01 RLN4997A 3/20/2002
HVN9060B CD   TELARIO TMT   R01.00.03.01 RLN4997A 08/11/00
RVN4123G 3.5 DOS VISAR PRIVACY PLUS 6881073C90 R04.00.01 RPX4719G 01/31/97 Yes 3080371E46
RVN4333A 3.5   VRM 100 TOOLBOX 6802944C40 V3.70 RPX4719G 06/28/96   FKN4486A cable & adapter
RVN4133K 3.5   VRM 500/600/650 6802946C95 R03.01.03 RPX4719G 6/18/2002 No
RVN4181E CD 98, ME, NT, 2000, XP XTS2500/5000 PORTABLES 6881095C44 R01.04.01 RPX4719G 7/26/2002   RKN4105A/RKN4106A
RVN4100 replaced by RVN4182 or RVN4183 2-3.5 DOS XTS3000 ASTRO PORTABLE/MOBILE
RVN4100U 3.5 DOS XTS3000 6881074C70 R09.01.00 NLA - SUBS TO RVN4184 Yes RKN4035D
RVN4182E
contains: RVN4100, important notice sheet, letter
1-CD
2-3.5
98, ME, NT, 2000,
DOS
XTS3000 / SABER (PORT)   R01.04.00 RPX4719G 06/19/02 Yes RKN4046A
RVN4170D 3.5 DOS XTS3500 6881089C82 R02.00.03 RPX4719G 11/09/00 Yes RKN4035D
Forum: Radio Equipment
 Topic: ForSale CHEAP PRICE RADIO Kc6wir@yahoo.com
ForSale CHEAP PRICE RADIO Kc6wir@yahoo.com [message #3022] Mon, 04 November 2013 07:06
raymtcn73  is currently offline raymtcn73
Messages: 2
Registered: November 2013
Junior Member
Flex-5000 100 Watt SDR Transceiver ...........$1550 /1175 Euro
ACOM 1000 ....................................$1600 /1215 Euro
AmeritronAL-1500 .............................$2100 /1594 Euro
QRO HF-2500DX 160-10M HF Amp .................$1600 /1215 Euro
ICOM IC-7700 .................................$2200 /1670 Euro
ICOM IC 9100 .................................$1600 /1215 Euro
Icom IC-7000 .................................$750 /569 Euro
Icom IC 775DSP ...............................$1100 /800 Euro
Icom PW-1 ....................................$1700 /1290 Euro
ICOM IC-756-Pro III ..........................$1200 /911 Euro
KENWOOD TS-2000 ..............................$900 /650 Euro
Kenwood TL-922A HF amp .......................$750 /569 Euro
Alpha 9500 ...................................$3000 /2278 Euro
Ten Tec Orion II .............................$1300 /987 Euro
Ameritron A-l 1200 ...........................$800 /607 Euro
Elecraft K2 ..................................$500 /379 Euro
Elecraft K3/100 ..............................$1850 /1404 Euro
Yaesu FTDX 9000MP ............................$5500 /4176 Euro
Yaesu FTDX 5000MP ............................$3500 /2657 Euro
Yaesu FTDX 3000MP ............................$1600 /1215 Euro
YAESU FL-7000 SOLID STATE HF LINEAR AMPLIFIER.$1000 /725 Euro
Yeasu FT-857D w/ LDG Tuner....................$620 /450 Euro
Yaesu FT920 ..................................$750 /569 Euro

I can ship worldwide.
All radios are in a perfect working condition
Kc6wir@yahoo.com
+1 8323232144.
kc6wir
Raymond.

  • Attachment: Forums.jpg
    (Size: 46.82KB, Downloaded 356 time(s))

 Topic: ADI AT600 Radios - HELP
icon9.gif  ADI AT600 Radios - HELP [message #209] Sun, 27 September 2009 15:29
RBoyette  is currently offline RBoyette
Messages: 2
Registered: September 2009
Location: Ft Myers, FL
Junior Member
Still have my old SAR radios and pulled them out after years of being put away. Still work but I need a manual or someone who knows how to program them. I also need to know where I can get new batteries for them. I am doing mounted patrol work now and would like to have these with me in case we do a recovery or event.
Any help would be greatly appreciated.


RBoyette
Forum: Rasberry Pi
 Topic: Raspberry Pi 1Wire DS18B20 Thermometer
Raspberry Pi 1Wire DS18B20 Thermometer [message #3021] Sat, 02 November 2013 22:20
kc2nda  is currently offline kc2nda
Messages: 29
Registered: December 2004
Location: New Paltz
Junior Member
I will be controlling a 12V Fan with a Raspberry Pi and a DS18B20 waterproof thermometer. The DS18B20 uses 3 wires even though they call it a 1wire system. The one wire is actually what makes the communication the other two is power and ground. I purchased the DS18B20 thermometer from ebay and they were pretty cheap. The DS18B20 thermometer was in a waterproof shell. The only problem I had which took me about 2 nights worth of playing around with the coding, the Raspberry Pi, and the 1wire DS18B20, was the wiring diagram that was on the Chinese seller's website of the DS18B20 stated that the yellow wire was ground and the green wire was the data line. This was wrong. Usually green is the common wire and I was a little skeptical at first but figured it was from China so anything is possible.

Of course, I didn't have any other 1wire devices to test on the Raspberry Pi. I couldn't test to make sure the Raspberry Pi was not functioning or the 1Wire DS18B20 was not functioning. Finally I took a chance and reversed the ground and data lines and it worked like a charm.

The 12V fan will also be controlled by the Raspberry Pi. A 555 timer will be used in conjunction with a digital potentiometer to adjust the fan speed.

Project pictures and circuit diagrams will follow.
Forum: Repairs
 Topic: Rigol DS1052E Hack to 100MHz
Rigol DS1052E Hack to 100MHz [message #1770] Wed, 02 January 2013 05:37
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
The Rigol DS1052E 50MHz scope arrived and it has been sitting for about a year (I guess maybe it is out of the warranty now anyway, so time for the HACK!) We finally got around to hacking the 50MHz beast to 100MHz. The unit came shipped with 00.02.05 SP1 firmware. This was tricky because RIGOL knew about all of the hacking going on. They put a stop to downgrading the firmware with the 00.02.05 firmware version.

The only way to hack this unit is to downgrade it to the 00.02.02.02 firmware. This firmware allowed you to change the serial number and model number which changes the scope to 100MHz. To do this, you need to use a USB or Serial port with special commands. Any newer firmware than 00.02.02.02 supposedly removed this feature. The trick was to take the 00.02.02.02 firmware and change the header on the file to reflect a larger firmware version. RIGOL also obscured the firmware version in their new firmware (02.05) so it isn't as easy as changing the numbers intuitively. With the right combination and a hex editor, the firmware was patched to make the scope think that the firmware was newer, but in fact, it was the old 00.02.02.02 firmware! Nice hack that actually works!

Linux was not playing well with the serial port and USB port, so Windows was used to make the serial/model number changes. After wondering why Windows was only recognizing it as a hard drive, the option for "Computer" was found in the "I/O Setup" for "USB Device". Once that was changed to "Computer", Windows recognized the RIGOL unit and the numbers were able to be changed. I bet this was the only problem with Linux also. But the job is done and there is no need to go back to try Linux at this point.


I wonder if the hack actually increased their sales or lost them money due to everyone purchasing the same unit for half the price? I know the purchase of this particular unit was because it could be hacked to 100MHz so my opinion is they gained more business and publicity from it.

http://www.hamradio.cc/images/projects/rigol/RIGOL_ds1052E-Hacked.jpg

[Updated on: Thu, 03 January 2013 02:53]

 Topic: GeForce 7600 GT 1500uF 6.3V FZ71 - Bad Capacitors
GeForce 7600 GT 1500uF 6.3V FZ71 - Bad Capacitors [message #304] Wed, 10 November 2010 01:44
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
I had the same problem many people are having with the GeForce 7600 GT video cards. I had 2 x GeForce 7600 GT cards in the same machine (...running 4 monitors...). The 1500uF capacitors are all crap. They probably cheaped out on them when manufacturing. On one card I had 2 caps blown across the inductor. But I pulled all of the 1500uF 6.3V caps on the board and tested them all. ALL of them failed their leakage test. So the best thing to do on those is to replace them all. Even if they look good, replace them. The 1000uF 16V cap tested fine. Cards work great afterwards...
Forum: New Hams and Hams in the Making
 Topic: New Elecraft K3/P3 & Yaesu FTDX5000MP AD6xJ@LIVE.COM
New Elecraft K3/P3 & Yaesu FTDX5000MP AD6xJ@LIVE.COM [message #3008] Sat, 21 September 2013 22:55
AD6XJ  is currently offline AD6XJ
Messages: 3
Registered: September 2013
Junior Member
I have a Yaesu FTDX5000MP HF Transceiver for sale.
Comes with all accessories, triple box and manual.The radio comes from a non-smoking environment,
comes with all factory box's, manuals, SM-5000 panadapter/speaker, Remote Keypad, power cord.
Software versions are current.
Price: $2,700usd/€2,000Euro

For sale is my Elecraft K3/P3 station.
Included 100 watt amp, antenna tuner, 250 and 400 hz 8 pole filters, KXVA3A, KTCXO3, Panadaptor P3 and hand mic.
Includes interconnecting cable (P3 to K3), K3 pwr leads and all manuals. Latest firmware.
Never around smoke. Never portable.
Works great like new, just not for me.
Asking: $1900usd/€1,410Euro

I can ship worldwide via DHL FedEx or UPS.

Call: (+1) 909-999-3834
Email: AD6xJ@LIVE.COM
Mr.Robert
73 and God Bless
AD6xJ
 Topic: radio operation
radio operation [message #151] Tue, 18 December 2007 15:40
N8HUW  is currently offline N8HUW
Messages: 2
Registered: December 2007
Junior Member
here it is I am sure a question you are shaking your heads at but oh well. Just purchased a Yaseau 767GX looks to be in good shape. Anyway Put it on an swl antenna I seem to be receiving beacons and so forth. The problem is when I first turned it on the VFO dial would move the radio thru about 1 mhz and then repeat. Now it wont move the readout at all I can use the up down button and tune thru the band but I am sure its way to course to find anything. Just need some help figureing out id the dial is OK and if so how to get it to tune. If not a suggestion for getting the radio gone thru so I can get on the air. Working on an antenna to be able to transmit


Mike
Forum: Alinco Mods
 Topic: Alinco DJ-162 Mod Extended RX/TX
Alinco DJ-162 Mod Extended RX/TX [message #2997] Sat, 06 July 2013 01:09
root  is currently offline root
Messages: 145
Registered: December 2004
Senior Member
Extended RX/TX for Alinco DJ-162

1. Remove the battery pack. Remove the battery plate from the bottom of the radio.
2. Remove the back cover from the radio. This is a tedious process. You must take the knobs off the top and remove the top plate first.
3. Under the Battery clasp on the side of the radio (The little sliding thumb switch that keeps the battery from falling off the radio) you will find a yellow loop of wire. This loop is small and hard to get to. You will need a very small pair of cutters or scissors.

--Cut this wire.

4. Put the radio back together

5. Reset the radio. (You will lose your memories)

6. Go to the VFO mode.
Pressing the 'B' key on the keypad will now allow
you to cycle through the extended rx bands. It will cycle from 2 mtrs, am aircraft, to 800. The radio does NOT have the guts to receive 800. It just happens to be in the processor so don't waste your time listening.

7. This same jumper also opens extended transmit.

Ron Wright - KA5LUG
Pages (6): [ «    1  2  3  4  5  6    »]


Current Time: Mon Sep 1 09:37:52 EDT 2014

Total time taken to generate the page: 0.09984 seconds
.:: Contact :: Home ::.

Powered by: FUDforum 2.7.6.
Copyright ©2001-2007 FUD Forum Bulletin Board Software
